Description:

Introducing Amphenol’s newest innovation – TRACER Rapid Prototyping. Achieve any pin-out you can imagine – without sacrificing performance or lead time. Thanks to Amphenol’s revolutionary insulator technology (patent pending), we can rapidly produce connectors in any contact configuration and get you fully functional sample pieces within a week.

Tracer is available on the following product series:

  • MIL-DTL-38999
  • Reverse-Bayonet GT
  • MIL-DTL-5015
  • 2M Micro38999
  • Hermetic & Sealed
  • And More

Tracer Pattern Design Tool is available in the Documents section below.

Features & Benefits:

FOR NEW DESIGN PROTOTYPING:

  • PC boards with cramped layouts that have
    difficulty routing traces out of traditionally
    concentric MIL-STD-1560 insert layouts
  • Applications that need additional insulation
    between their power and signal wiring
  • Customers who want to avoid using sealing
    plugs in unused cavities
  • Customers who need a path to production
    that avoids long-lead tooling

For Board Designers

  • Flexible trace routing for board layer reduction
  • Place your board through-holes anywhere for
    easy trace routing
  • Mount board level components under
    circular connectors

For Everyone

  • Fully customizable pin-outs
  • Samples available in 10 days or less
  • Can offer variable levels of sealing
    environmental ingress protection
  • Offers a bridge to full-rate production
Tracer Data Sheet
With Tracer Rapid Prototyping, achieve any pin-out you can imagine – without sacrificing performance or lead time.
Tracer Pattern Design Tool
Click here to download a .zip file that includes all of the documents needed to design your own custom insert pattern.
